Feature:
1. This servo control module can stably control the servo motor to work within a safe torsion and never drop the line.
2. This servo controller is perfectly compatible with for Futaba/JR/SANWA/Hitec and other remote control systems.
3. The multi‑stage steering gear control board has high sensitivity, high torsion, a large stroke, and zero blind spots.
4. Enables input signals from remote control, multi‑channel steering gear controller and single‑chip microcomputer.
5. Has a small size and a light weight, the installation is very simple to complete, also very durable for long‑term use.
Specification:
Item Type: Servo Control Board
Material: Glass Fiber
Working Voltage: 12V to 24V (DC) (any voltage between 12V or 24V can be used)
No-Load Rotating Current: Maximum Torsion: 180kg.cm (24V) (actual measurement, not theoretically calculated value)
1764N.cm(24V) (actual measurement, not theoretically calculated value)
90kg.cm(12V) (actual measurement, not theoretical calculation value)
882N.cm(12V) (actual measurement, not theoretical calculation value)
Angular Speed: 0.5s/60° (0.5s is required to rotate 60 degrees), at 24V;
1.0s/60°(1.0s is required for 60°rotation), at 12V;
Rotation Angle: 300° Maximum (0 to 300° electronic limit adjustable)
Input Mode: Pulse Signal (remote control, multi-channel steering gear controller, single-chip microcomputer) or analog voltage signal (potentiometer).
Pulse Signal Input Range: 0.5ms-2.5ms suitable for all "multi-channel steering gear controllers", "1ms-2ms model airplane remote control", "MCU programming", etc.;
Voltage Signal Input Range: 0V to +5V
Control Accuracy: 0.32°
Package List:
1 x Servo Control Board
4 x Screw
Note:
Do not use it outside the range of voltage and current parameters.
