DPS100 Pocket Size Bench Switching 30V 5A 100W Max Programmable Voltage Regulator Power Supply DC LAB Supply Power Supplies

DPS100 Pocket Laboratory DC Power Supply 30V 5A 100W Max Mini Portable Switching Power Supply Programmable Voltage Regulator Power Supply Features:

1.Versatile Input Compatibility: Featuring both Type-C and DC input interfaces, this pocket laboratory dc power supply supports a wide 5~32V DC voltage range, giving you flexibility for diverse powering needs while maintaining efficient and reliable performance. 2.Precise Control & Adjustment: With hardware-controlled constant current and constant voltage output, the adjustable voltage regulator provides fine tuning from 0V and 0A, allowing accurate settings for sensitive electronics and enhanced project safety. 3.High Efficiency & Stability: Designed with low ripple and high efficiency architecture, this pocket size bench switching unit keeps your devices safe and stable, minimizing noise and maximizing power delivery throughout a wide range of loads. 4.Smart Programmable Output: Take advantage of 10 preset output groups for instant recall on repeated tasks. The mini portable switching power supply makes switching configurations simple, saving you setup time in the workshop or on the go. 5.Comprehensive Protection & Monitoring: Supporting input undervoltage/reverse protection and output overvoltage, overcurrent, overload, overtemperature, and reverse connection safeguards, the programmable voltage regulator power supply also measures input voltage/current for real-time status tracking. Specification: Origin: Mainland China Measurement Resolution: Input Voltage: 10mV Input Current: 1mA Output Voltage: 10mV Output Current: 1mA

Measurement Accuracy: Input Voltage: ≤0.2% ±10mV Input Current: ≤0.1% ±5mA Output Voltage: ≤0.1% ±10mV Output Current: ≤0.1% ±5mA

Parameters: Display: 2.4-inch color screen Input Voltage: DC 5.0-32V, 30mA-5A Type-C Interface Supported Protocols: PD 3.0/2.0, BC 1.2, etc. Output Interface: 4.0mm banana connector Output Range: Voltage: 0-30V / Current: 0-5A / Power: 100W (Max) Setting Resolution: Voltage: 10mV / Current: 1mA Accuracy: Set Value: Voltage: ≤0.1%±5mV / Current: ≤0.1%±3mA Load Regulation: Output Voltage: ≤0.05%±5mV / Output Current: ≤0.1%±3mA Power Regulation: Voltage: ≤0.05%±5mV / Current: ≤0.1%±3mA Ripple and Noise: Voltage: ≤2mVrms, 10mVp-p / Current: ≤1mArms, 3mAp-p Output Temperature Coefficient: Voltage: ≤200ppm / Current: ≤200ppm Full Load Efficiency: ≤97% @100W (30V, 3.334A) Operating Environment: 0°C-40°C, 0-75% RH Casing Material: ABS Size: about 110.00 x 70.00 x 20.00 mm / 4.33 x 2.76 x 0.79 inches

Note: Due to different monitor settings and lighting conditions, the actual color of the item may vary slightly from the pictures. Thanks for your understanding! Please allow a 1-2 cm difference in measurements due to manual measuring.

1 x Main Unit 1 x Test Clip 1 x English Instruction Manual
