Feature:
1. 2.8 Inch Resistive Touch Screen: This thermal imager uses a 2.8 inch color display, with 320x480 high resolution, resistive touch screen operation, with one key function.
2. 2 In 1 Design: This digital multimeter has a 2 in 1 design, featuring a handheld thermal imaging camera with high thermal imaging pixels, 4000 count digital multimeter functionality, and support for dual mode switching between thermal imaging camera and multimeter.
3. UFPA Sensor: This thermal imaging device uses a UFPA sensor with an image acquisition frequency of 6Hz, (768) thermal imaging pixels of 24 x 32, field of view (FOV) of 55°(H) x 35°(V), emissivity is adjustable from 0.1 to 0.99(default 0.95),temperature range of ‑40℃ to 300℃.
4. Multifunctional: This Ohm Volt Amp meter is multifunctional and supports AC or DC voltage, resistance, capacitance, diode, on and off test, frequency, duty cycle measurement.
5. Excellent ABS Material: This thermal imager multimeter is made of excellent ABS material for the shell, which is sturdy and wear resistant, not easy to be damaged, and has a long service life.
Specification:
Item Type: Thermal Imaging Digital Multimeter
Thermal Imaging Parameters:
Model: ET11S
Sensor: Uncooled Focal Plane
Image Capturing Frequency: 16Hz
Thermal Imaging Pixels: (768)24 x 32
Display Image Resolution: 187 x 251
Field Of View (FOV): 55°(H) x 35°(V)
Emissivity: 0.1-0.99 Adjustable, Default 0.95
Measurement Temperature Range: -40°C-300°C
Mode: Auto Gain
Color Palette: Iron Red, Rainbow
Measurement Temperature Error: ±2℃ or ±2%
Display Temperature Accuracy: 0.1℃/0.1℉
Multimeter Parameters:
DC Maximum Input Voltage: 1000V
Maximum AC Input Voltage: 750V
Resistance Maximum Measured Resistance Value: 40MΩ
Capacitance Maximum Measuring Value: 100uF
Duty Cycle Measurement Range: 0.1%-99.9%
Diode Measurement Range: 0V-1.5V
Maximum Resistance Value of On And Off Detection: 30Ω
Display Number: 4000 counts Updated About 3 Times Per Second
Other Parameters of Device:
Display Screen: 2.8 Inch 320 x 480 Resolution
Touch Screen: Resistive Touch Screen
USB Interface: Type C USB
Storage Capacity: 3.5MB
Image Format: BMP File
Battery: 3.7V Lithium Battery 1000mAh x 1 ( Shipped With Built In Battery )
Storage Temperature: -20-60℃ (-4-140℉)
Operating Temperature: 0-50℃ (32-122℉)
Operating Humidity: Size(LxWxH): Approx. 134 x 69 x 25mm / 5.28 x 2.72 x 0.98in
How to Use:
Check the manual for applicable.
Package List:
1 x Thermal Imaging Multimeter
2 x Test Leads
1 x USB Cable
1 x Manual
