Label:Yes
4. Versatile Applications:Suitable for automotive climate control, industrial moving parts, printers, copiers, household appliances, livestock monitoring, and other temperature-sensing scenarios.
5. Compact Design:With its small form factor and pre-soldered pin headers, the module is easy to install and designed for accurate operations in space-constrained setups.
1. Wide Temperature Sensing Range:This IR temperature sensor module measures ambient temperatures from -40°C to 120°C and object temperatures from -70°C to 380°C.
3. Technical Specifications:The temperature sensor module adopts 10 bit PWM output mode, compatible for SMBus digital interface, and has stable performance.
2. Accurate and Stable Measurement:Within the range of 0°C to +50°C, the sensor achieves a measurement accuracy of up to ±0.5°C with a resolution of 0.02°C, supporting consistent and reliable readings.
Specifications:
Item Type: IR Temperature Sensor Module
Power supply: 3-5V (internal low voltage differential stabilization)
Communication method: Standard IIC communication protocol
Temperature Resolution: 0.5℃
Output Mode: 10 bit PWM (pulse width modulation) output
Interface: For SMBus compatible protocol interface
Temperature Range:
Environment Temperature: -40-120℃
Object Temperature: -70-380℃
BCC distance measurement: 10cm(3.94in)
Color: Blue+Black
Size: 11.5 * 16.5mm(0.45 * 0.65in)
Application:
High accuracy non contacts measurement
Used in automotive air conditioning control systems, residential, commercial, and industrial buildings
Windshield anti fog application
Dead angle detection of automotive field of view
Temperature control of industrial mobile components
Temperature control of printers and copiers
Home appliance temperature control
Healthcare
Livestock monitoring
Moving object detection
Multi zone temperature control, 2 wire comm capable of supporting up to 100 sensors
Thermal relay, alarm
Body temperature measurement
Package List:
1 x Sensor Module
1 x Pin Header
Note:
1. Due to the difference between different monitors, the picture may not reflect the actual color of the item.
2. Please allow slight dimension difference due to different manual measurements. Thank you for your understanding.
