1.5Msps Sampling Rate DC 5V Oscilloscope Digital Oscilloscope 500kHz Bandwidth

Features: 1. Single-board design: Compact, integrated structure, easy installation, and high stability, suitable for various experimental environments. 2. Built-in signal generator: Integrated waveform output functions such as sine and triangle waves meet various testing needs. 3. Waveform storage and recall: Supports waveform storage and quick recall, facilitating comparison, analysis, and reuse. 4. 500kHz high bandwidth: High-frequency response enables accurate of complex signal details. 5. An for ideal tool for electronics enthusiasts: Simple to operate and powerful, it is a valuable aid for learning electronics and exploring the world of circuits.

Specifications: Part Name: DC 5V DSO183 Digital Oscilloscope Material: ABS Color: As shown Bandwidth: 500kHz

for ADC Accuracy: 12- Real-time Sampling Rate: 1.5Msps Waveform Buffer Length: 1024 points Vertical Sensitivity Range: 10mV/gram - 5V/gram Input Impedance: 1MΩ Maximum Input Voltage: 50Vpk Coupling: DC, AC, GND Horizontal Timebase Range: 1µs/gram - 500s/gram Trigger Mode: Auto, Normal, Single Trigger Edge: 1µs/gram - 500s/gram Power Supply: DC 5V (via Type-C) Current Consumption:
