Feature:
1. [100m Wireless Distance] Allows users to experience wireless streaming of HD content, with the ability to extend HD video and sound to any HDTV screen beyond 100 meters.
2. [Good Performance] Support HD mirror output and infrared remote control expansion, the receiver supports HD loop output, used for local screen monitors, more convenient to use.
3. [Efficient And Anti Interference] 5GHz high frequency wireless AV transmission, high transmission rate, more efficient expansion performance, with strong anti interference ability.
4. [Multi Resolution Support] This wireless HD Multimedia Interface extender supports 480p, 720p, 1080p, 2160p at 60 50 30 25 24 HD resolutions, giving you the best video experience.
5. [Wide Applicability] Supporting multiple to one or one to multiple connections, this extender is widely suitable for office presentations, lectures, education, conferences, home entertainment, etc.
Specification:
Item Type: Wireless HD Multimedia Interface Extender
Material: Metal
Interface: TX: 1 x HD Multimedia Interface IN, 1 x HD Multimedia Interface OUT, 1 x AUX IN, 1 x IR OUT, 1 x RS232, 1 x Micro USB, 1 x DC JACK
RX: 1 x HD Multimedia Interface OUT, 1 x AUX OUT, 1 x IR IN, 1 x RS232, 2 x USB2.0, 1 x DC JACK
HD Multimedia Interface Input Resolution: 480P, 720P, 1080P, 2160P, at 60, 50, 30, 25, 24
HD Multimedia Interface Loop Out Resolution: Follow Input, No Delay
HD Multimedia Interface Output Resolution: 480P, 720P, 1080P at 60, 4K at 30 When 4K Output
HD Multimedia Interface Sound Mode: LPCM (4844.132kHz 162024bit)
Input and Output TMDS Signal: 0.5~1.5Vp-p (TTL)
Transmission Delay: About 80ms
Wireless Transmission Standard: 802.11 ac WiFi MIMO Technology
Wireless Transmission Frequency Band: 4.900GHz-5.845GHz (5GHz ISM Band)
Wireless Type: External Dual 5dBi Gain Antenna
Wireless Transmit Power (IPEX): 802.11ac, MCS9: 15 DBm+-1.5dB at EVM less than -32dB
Wireless Transmission Distance: less than 100m328ft
IR Carrier Frequency Range: 20-60kHz
Power Specification: AC100-240V, Output: DC 12V1A
Maximum Working Current: TX less than 400mA, RX less than 300mA
Working Temperature: 0~40 celsius .
Package List:
1 x Transmitter1 x Receiver1 x Infrared Transmission Line1 x Infrared Receiving Line2 x Power Adapter1 x Data Cable2 x RS232 Connector1 x Manual
