UTi120S Infrared Thermal Imager 120x90Pixel IR Resolution Multifunctional Handheld Thermal Imaging Camera
Feature:
1. 6 Color Palettes: The palette menu provides six palettes of white hot, black hot, rainbow, lava, iron red, and high contrast rainbow for selecting the infrared image mode to be captured.
2. USB Input and Output: Built in rechargeable lithium battery, which can be charged via USB. The saved image can be exported via a USB cable connected to a computer.
3. LED Light: With LED light, the thermal imager camera can quickly identify the object under test even in dimly lit scenes.
4. Multi Function: Anti drop function between 2m / 6.5ft, no fear of falling, safe and secure. IP54 dustproof and waterproof, the application range is wider.
5. Wide Range of Application: This thermal imager is widely used in fire protection, archaeology, transportation, agriculture, geology, energy, smelting, electronic manufacturing and other fields. It is an ideal choice for electricians and maintenance technicians, and can be used to quickly find problem areas.
Specification:
Item Type: Infrared Thermal Imager
Model: UTi120S
Material: ABS
Product Color: As Pictures Shown
Product Weight: Approx. 553g / 19.5oz
Battery: Rechargeable lithium battery 3.7V 2600mAh (built in)
Detector Type: Uncooled Vanadium Oxide
Pixel Pitch: 17μm
Response Band: 8-14μm
Infrared Resolution: 120x90 Pixels
Thermal Sensitivity (netd): Field of View (FOV): 50°(h)x38°(v)
Spatial Resolution (ifov): 7.6mrad
Frame Rate: ≤25hz
Minimum Imaging Distance: 0.1m / 0.3ft
Focusing: No Focusing
Temperature Measurement Range: -20℃-400℃
Temperature Measurement Accuracy: ±2% or ±2°; Take the Maximum Value (-10℃-400℃, Normal Temperature 25℃)
Temperature Measurement Unit: Celsius, Fahrenheit
Temperature Measurement Resolution: 0.1℃
Emissivity: 0.95 (default) (0.01-0.99 Adjustable)
Temperature Measurement Display: Central Point Temperature Measurement, High and Low Temperature Tracking
Palette: Lava, High Contrast Rainbow, Black Hot, White Hot, Iron Red, Rainbow
Display: 2.44inch for Tft LCD
Display Resolution: 320x240
Buttons: 4 Buttons (power button, up button, down button, OK button), 1 Trigger Button
Indication: Yes (level 2)
LED Light: Yes
Temperature Alarm: Screen Alarm, LED Light Alarm, Buzzer Alarm
Image Storage: Micro Memory Card
Image Format: BMP
PC Analysis Software: Yes
Data Communication: Type C
Uses: This product is widely used in fire protection, archaeology, transportation, agriculture, geology, energy, smelting, electronic manufacturing and other fields. It is an ideal choice for electricians and maintenance technicians, and can be used to quickly find problem areas.
Package List:
1 x Thermal Imager
1 x USB Data Cable
1 x Memory Card
1 x Manual
1 x Lanyard
Note:
Maintenance: Clean the structural shell with a damp cloth or weak soap and liquid. Do not use abrasives, isopropanol or solvents to clean the lens/window of the instrument shell.
